Lifting Electromagnets for Lifting Steel Plates
This series is specially designde for lifting and transporting medium-thick steel plate.The whole operation is safe,exact and quick,When transport some long plates they easily go disto rtion.so we advice combination of multiple units to be used.For some plate which thickness is around the range of 6mm-32mm,space between 2 magnets should leave an extra 2.5-3.5m,the length at each end is that of one half of space.According to different lifting pieces,the series is divided into type 350 and type 400and type 500and type 650.Type 350 is suitable for medium-thick plate factory,ship building factory.machinery manufacturing factory,lt is controlled by adjustable magnetic field,and can litt one or certaln pieces of plates.Type 400 ls suitable for lifting as many as possible pieces at a time；we can also produce the product less than 700C（high temperature type）for you.
Series MW84-口35
Main technical data(rated voltage DC-220V, duty cycle TD-60%)
| Model | Cold-state Power (kw) |
Cold-state Current (A) |
Overall dimension (mm) |
Mass (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | ||||
| MW84-9030T/1 | 0.4 | 1.9 | 900 | 350 | 900 | 350 | 110 | 180 | 32 | 185 |
| MW84-10535T(L)/1 | 0.9(1.4) | 4.1(6.4) | 1050 | 350 | 960 | 400 | 110 | 180 | 32 | 330 |
| MW84-14035T(L)/1 | 1.2(1.87) | 5.5(8.5) | 1400 | 350 | 940 | 500 | 110 | 180 | 32 | 430 |
| MW84-17535T(L)/1 | 1.5(2.35) | 6.8(10.68) | 1750 | 350 | 940 | 700 | 110 | 180 | 32 | 510 |
| MW84-21035T(L)/1 | 1.8(2.8) | 8.2(12.7) | 2100 | 350 | 920 | 800 | 110 | 180 | 32 | 600 |
| MW84-24535T(L)/1 | 2.5(3.3) | 11.4(15) | 2450 | 350 | 980 | 850 | 110 | 180 | 32 | 720 |
| MW84-26035L/1 | 3.35 | 15.2 | 2600 | 350 | 1050 | 850 | 110 | 180 | 35 | 855 |
| MW84-26035L/2 | 3.1 | 14.1 | 2600 | 350 | 1080 | 850 | 110 | 180 | 35 | 900 |
Note:rated voltage of MW84-9030T/1 is DC-110V
How many pieces of steel will be definitely lifted(for example)
Note:MW84-9030T/1, which adopts combination of four units can lift and transpprt plate of length 3000-6000, width 900-1900,thickness 4~10(mm)
Series MW84-口40
Main technical data(rated voltage DC-220V, duty cycle TD-60%)
| Model | Cold-state Power (kw) |
Cold-state Current (A) |
Overall dimension (mm) |
Mass (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | ||||
| MW84-12040L/1 | 3.0 | 13.6 | 1200 | 400 | 1020 | 400 | 110 | 180 | 30 | 550 |
| MW84-16040L/1 | 3.2 | 14.5 | 1600 | 400 | 1000 | 700 | 110 | 180 | 35 | 690 |
| MW84-20040L/1 | 5.0 | 22.7 | 2000 | 400 | 970 | 800 | 110 | 180 | 35 | 840 |
| MW84-24040L/1 | 6.0 | 27.3 | 2400 | 400 | 890 | 850 | 110 | 180 | 35 | 910 |
| MW84-13042L/2 | 2.4 | 10.9 | 1260 | 420 | 1040 | 500 | 110 | 180 | 30 | 650 |
| MW84-17042L/2 | 3.7 | 16.8 | 1680 | 420 | 1050 | 700 | 110 | 180 | 35 | 850 |
| MW84-21042L/2 | 4.0 | 18.2 | 2100 | 420 | 1000 | 800 | 110 | 180 | 35 | 1050 |
| MW84-25042L/2 | 4.8 | 21.8 | 2520 | 420 | 990 | 850 | 110 | 180 | 35 | 1250 |
How many pieces of steel will be definitely lifted(for example)
Series MW84-口50
Main technical data(rated voltage DC-220V, duty cycle TD-60%)
| Model | Cold-state Power (kw) |
Cold-state Current (A) |
Overall dimension (mm) |
Mass (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | ||||
| MW84-13050L/1 | 2.6 | 11.8 | 1300 | 500 | 1150 | 700 | 110 | 180 | 35 | 780 |
| MW84-18050L/1 | 3.3 | 15 | 1800 | 500 | 1200 | 800 | 110 | 180 | 40 | 1180 |
| MW84-26050L/1 | 5.1 | 23.2 | 2600 | 500 | 1250 | 850 | 110 | 180 | 45 | 1480 |
| MW84-13050L/2 | 2.5 | 11.4 | 1300 | 500 | 1180 | 700 | 110 | 180 | 35 | 830 |
| MW84-18050L/2 | 3.1 | 14.1 | 1800 | 500 | 1230 | 800 | 110 | 180 | 40 | 1170 |
| MW84-26050L/2 | 4.9 | 22.3 | 2000 | 500 | 1280 | 850 | 110 | 180 | 45 | 1590 |
How many pieces of steel will be definitely lifted(for example)
Series MW84-口65
Main technical data(rated voltage DC-220V, duty cycle TD-60%)
| Model | Cold-state Power (kw) |
Cold-state Current (A) |
Overall dimension (mm) |
Mass (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | G | ||||
| MW84-13065L/1 | 4.5 | 20.5 | 1300 | 650 | 1050 | 600 | 100 | 220 | 40 | 1370 |
| MW84-20065L/1 | 6.8 | 30.9 | 2000 | 650 | 1050 | 600 | 100 | 220 | 50 | 2050 |
| MW84-26065L/1 | 9.1 | 41.4 | 2600 | 650 | 1150 | 700 | 100 | 220 | 55 | 2790 |
How many pieces of steel will be definitely lifted(for example)
| width of steel plate | model- pieces of steel to be lifted |
plate thickness (mm) |
||||||
|---|---|---|---|---|---|---|---|---|
| 6 | 8 | 10 | 12 | 16 | 20 | 32 | ||
| 1500(mm) | MW84-13065L/1 | 10 | 7 | 6 | 6 | 5 | 4 | 3 |
| MW84-20065TL/1 | 11 | 8 | 7 | 6 | 5 | 4 | 3 | |
| MW84-26065TL/1 | 11 | 8 | 7 | 6 | 5 | 4 | 3 | |
| 2500(mm) | MW84-13065L/1 | 6 | 6 | 5 | 5 | 4 | 3 | 2 |
| MW84-20065TL/1 | 10 | 7 | 7 | 6 | 5 | 4 | 3 | |
| MW84-26065TL/1 | 11 | 8 | 7 | 5 | 5 | 4 | 3 | |
| 4000(mm) | MW84-13065TL/1 | / | / | / | 3 | 2 | 2 | 1 |
| MW84-20065L/1 | / | 3 | 4 | 4 | 3 | 2 | 2 | |
| MW84-26065L/1 | 5 | 5 | 5 | 5 | 4 | 3 | 2 | |
Series MW04
Main technical data
